15kV 0.47uF High Voltage Pulse Capacitor

1-1.2 USD ($)/Piece

Get a Price/Quote

Product Details:

Current DC
Frequency 1 Hertz (HZ)
Product Type Polypropylene Film Capacitor
Material Film
Capacitance 0.47uF,0.47MFD,470nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 15kV,15000 Volt (V)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

15kV 0.47uF High Voltage Pulse Capacitor Price And Quantity

Minimum Order Quantity 20 Piece
Price 1-1.2 USD ($)/Piece

15kV 0.47uF High Voltage Pulse Capacitor Product Specifications

Material Film
Rated Voltage 15kV,15000 Volt (V)
Terminal Single-Ended
Product Type Polypropylene Film Capacitor
Frequency 1 Hertz (HZ)
Operating Temperature -10~+40 Celsius (oC)
Application High Voltage, Power, General Purpose
Capacitance Tolerance +/-10% Microfarad (F)
Current DC
Capacitance 0.47uF,0.47MFD,470nF

15kV 0.47uF High Voltage Pulse Capacitor Trade Information

FOB Port Shanghai
Payment Terms Western Union, Paypal, Telegraphic Transfer (T/T)
Supply Ability 200 Piece Per Week
Sample Policy Contact us for information regarding our sample policy
Packaging Details 5PCS/CTN
Main Export Market(s) Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Central America, Asia, Africa
Main Domestic Market All India
Certifications ISO9001

Product Description

Manufacturer/Supplier	Shanghai Pluspark Electronics Co.,Ltd
Product	High voltage capacitor
Rated capacitance -in uF	0.47uF,0.47MFD
-in nF	470nF
Capacitance tolerance	+/-10% (K),
Rated voltage VR	15Kv, 15000V.DC
Max. Continuous Rep Rate	1pps
Terminals	Single-ended, plastic case
Case size	58x152x235mm
Operating temperature range	-10 degree C~+40 degree C
Max .peak current	25kA
Max RMS current	25A
Design life	100,000 charge/discharge cycles

Rating of 15kV Capacitor:

Product category	High Voltage Capacitor
Item	Voltage	Capacitance-uF	Capacitance -nF
High Voltage Capacitor	15kV	0.47uF	470nF
High Voltage Capacitor	15kV	0.6uF	600nF
High Voltage Capacitor	15kV	2uF	2000nF
