20kV 0.32uF High Voltage Capacitor

1-1.2 USD ($)/Piece

Get a Price/Quote

Product Details:

Current DC
Frequency 1 Hertz (HZ)
Product Type Polypropylene Film Capacitor
Capacitance 0.32uF,0.32MFD,320nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 20kV,200000 Volt (V)
Capacitance Tolerance +/-10% Microfarad (F)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

20kV 0.32uF High Voltage Capacitor Price And Quantity

Price 1-1.2 USD ($)/Piece
Minimum Order Quantity 10 Piece

20kV 0.32uF High Voltage Capacitor Product Specifications

Product Type Polypropylene Film Capacitor
Capacitance Tolerance +/-10% Microfarad (F)
Frequency 1 Hertz (HZ)
Terminal Single-Ended
Capacitance 0.32uF,0.32MFD,320nF
Rated Voltage 20kV,200000 Volt (V)
Application High Voltage, Power, General Purpose
Operating Temperature -10~+40 Celsius (oC)
Current DC
Temperature Range -10~+40 Celsius (oC)

20kV 0.32uF High Voltage Capacitor Trade Information

FOB Port Shanghai
Payment Terms Telegraphic Transfer (T/T), Paypal
Supply Ability 200 Piece Per Week
Delivery Time 8-12 Week
Sample Policy Contact us for information regarding our sample policy
Packaging Details 5PCS/CTN
Main Export Market(s) Western Europe, Eastern Europe, Central America, Middle East, South America, Asia, North America, Australia, Africa
Main Domestic Market All India
Certifications ISO9001:2015

Product Description

HIGH VOLTAGE PULSE CAPACITOR 20KV 0.32uF(320nF)
Specifications
Capacitance	0.32uF/0.32MFD/320nF
Rated Voltage	20kV/20000V.DC
Capacitance Tolerance	10%
Minimum Operating Temperature	-10 C
Maximum Operating Temperature	+40 C
Max.Continuous Rep Rate	1pps
MAX Peak Current	25KA
MAX RMS Current	25A
Product Category	Pulse Capacitor
Part Number	PSE11014
Case Style	Single-Ended Plastic Case
Dimensions	L:152mm W:58mm H:275mm
Manufacturer	Shanghai Pluspark Electronics Co.,Ltd
