Energy Storage High Voltage Capacitor 100kV 4uF/4000nF

Get a Price/Quote

Product Details:

Insulation Resistance >5000 M (at 100VDC)
Breakdown Voltage >110% of Rated Voltage
Loss Tangent 0.0005 (at 1kHz)
Lead Spacing Depends on terminal design
Insulation Voltage >100kV
Surface Mount Land Size Not Applicable (Screw Terminal)
Frequency Low to Medium Frequency Applications
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Energy Storage High Voltage Capacitor 100kV 4uF/4000nF Price And Quantity

Minimum Order Quantity 10 Piece

Energy Storage High Voltage Capacitor 100kV 4uF/4000nF Product Specifications

Lead Spacing Depends on terminal design
Terminal High Voltage Screw Terminals
Rated Voltage 100kV (100,000 Volts)
Loss Tangent 0.0005 (at 1kHz)
Breakdown Voltage >110% of Rated Voltage
Ripple Low Ripple Current
Size Customized/Varies per model (contact supplier for exact)
Insulation Resistance >5000 M (at 100VDC)
Shell Aluminum Case
Application Pulse Power, Energy Storage, Medical, Industrial, High Voltage DC Systems
Capacitance Tolerance 10%
Temperature Range -40C to +85C
Product Type Energy Storage High Voltage Capacitor
Color Silver Gray
Current High Pulse Current Handling
Frequency Low to Medium Frequency Applications
Surface Mount Land Size Not Applicable (Screw Terminal)
Operating Temperature -40C to +85C
Capacitance 4F / 4000nF
Material Metallized Polypropylene Film
Insulation Voltage >100kV
Shape Cylindrical

Energy Storage High Voltage Capacitor 100kV 4uF/4000nF Trade Information

FOB Port Shanghai
Payment Terms Western Union, Paypal, Telegraphic Transfer (T/T)
Supply Ability 200 Piece Per Week
Delivery Time 45 Week
Sample Policy Contact us for information regarding our sample policy
Main Export Market(s) Asia, Australia, Central America, Western Europe, Middle East, Eastern Europe, South America, North America, Africa
Main Domestic Market All India
Certifications ISO9001

Product Description

Energy Storage High Voltage Capacitor 100kV 4uF/4000nF
Rated Voltage	100kV or 100000V.DC
Nominal Capacitance	4uF
	4 microfarad
	4MFD
	4MKF
	4000nF
Tolerance Range	+/-5%	+/-10%
Temperature Range	-10 C	+40 C
Max.Dissipation Factor	0.4%
Insulation Resistance	Min:1000M ohm
Manufacturer/supplier	Shanghai Pluspark Electronics Co.,Ltd
Application	High Energy Marx Generators
	High Energy physics experiments
	Pulse magnetic field generators
	Lasers, Particle Accelerators
Phone/Whatsapp	0086 13761174539
Attn	Phyllis Hou

High Performance and Reliability

This capacitor excels in high pulse current applications, ensuring stable performance even under rapid charge and discharge cycles. Its ultra-low ESR and high insulation resistance (>5000 M) allow for efficient energy flow with minimal heat generation, supporting extended operational lifespans.

Versatile Mounting and Design

With a panel mount design and cylindrical aluminum case, installation is straightforward for customized or standard arrangements. High voltage screw terminals provide secure and reliable connectivity, making it suitable for a range of medical, industrial, and energy storage systems.

Safety and Compliance

Designed to meet IEC standards and ROHS compliance requirements, this capacitor supports safe operations, with a breakdown voltage over 110% of its rating and optional discharge resistor for risk mitigation. Its robust build accommodates temperatures between -40C and +85C.

FAQ's of Energy Storage High Voltage Capacitor 100kV 4uF/4000nF:

Q: How is the Energy Storage High Voltage Capacitor 100kV 4uF/4000nF installed?

A: It is designed for panel mounting using high voltage screw terminals, ensuring secure and stable connections in energy storage and pulse power systems. The cylindrical aluminum case facilitates straightforward installation in customized or standard setups.

Q: What are the primary benefits of using an ultra-low ESR capacitor in high voltage applications?

A: Ultra-low ESR minimizes energy loss and heat generation during high pulse current operations, enhancing efficiency and longevity. This is critical for applications requiring rapid, repeated charging and discharging, such as pulse power and medical imaging equipment.

Q: When should the discharge resistor option be considered?

A: The optional discharge resistor is recommended for applications where residual charge must be safely dissipated after capacitor operation, reducing the risk of electrical hazards during maintenance or handling.

Q: Where can this capacitor be deployed effectively?

A: It is suitable for installation in medical devices, industrial equipment, energy storage systems, and high-voltage DC applications that require robust energy handling and long operational life.

Q: What materials are used in the construction of this capacitor?

A: The capacitor utilizes metallized polypropylene film for the dielectric, an aluminum case for structural integrity, and features high-voltage screw terminals for connection. These materials ensure reliable performance and compliance with safety standards.

Q: What process ensures the safety and durability of this capacitor?

A: Manufactured to IEC dielectric strength standards and tested for breakdown voltage above 110% of its rating, the capacitor offers exceptional durability. Its ROHS-compliant build and robust insulation resistance (>5000 M) further reinforce safety.

Q: How does the life expectancy benefit long-term applications?

A: With a rated lifespan of 100,000 hours under standard conditions, this capacitor delivers long-term reliability, reducing maintenance frequency and replacement costs in critical pulse power and energy storage applications.
