High Voltage Capacitor 45kV 0.03uF

1-1.2 USD ($)/Piece

Get a Price/Quote

Product Details:

Current DC
Product Type Polypropylene Film Capacitor
Capacitance 0.03uF,0.03MFD,30nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 45kV,450000 Volt (V)
Capacitance Tolerance +/-5% Microfarad (F)
Temperature Range -10~+40 Celsius (oC)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

High Voltage Capacitor 45kV 0.03uF Price And Quantity

Price 1-1.2 USD ($)/Piece
Minimum Order Quantity 10 Piece

High Voltage Capacitor 45kV 0.03uF Product Specifications

Temperature Range -10~+40 Celsius (oC)
Application Power, High Voltage, General Purpose
Current DC
Product Type Polypropylene Film Capacitor
Capacitance 0.03uF,0.03MFD,30nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 45kV,450000 Volt (V)
Terminal Double Ended Famale Terminal are opposite ends
Capacitance Tolerance +/-5% Microfarad (F)

High Voltage Capacitor 45kV 0.03uF Trade Information

FOB Port Shanghai
Payment Terms Telegraphic Transfer (T/T), Western Union, Paypal
Supply Ability 200 Piece Per Week
Delivery Time 4-6 Week
Sample Policy Contact us for information regarding our sample policy
Packaging Details 5PCS/CTN
Main Export Market(s) Western Europe, Australia, North America, Eastern Europe, Middle East, Central America, South America, Asia, Africa
Main Domestic Market All India
Certifications ISO9001:2015

Product Description

HIGH VOLTAGE PULSE DISCHARGE AND DC CAPACITOR 45KV 0.03uF(30nF)

Specifications:

Capacitance	0.03uF/0.03MFD/30nF
Rated Voltage	45kV/45000V.DC
Capacitance Tolerance	5%
Minimum Operating Temperature	-10C
Maximum Operating Temperature	+40C
Rated Voltage Reversal	20%
MAX Peak Current	25KA
MAX RMS Current	25A
Product Category	Pulse Capacitor
Part Number	DEF11029
Case Style	Double-Ended,Plastic Case
Dimensions	L:216mm W:154mm H:105mm
Manufacturer	Shanghai Pluspark Electronics Co.,Ltd

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Pulse Discharge And DC Capacitor' category

High Voltage Pulse Discharge and DC Capacitor 31.5nF 45000V Price : 1-1.2 USD ($)/Piece Minimum Order Quantity : 10 Application : High Voltage, Power, General Purpose Capacitance : 0.0315uF,0.0315MFD,31.5nF Product Type : Polypropylene Film Capacitor Current : DC Rated Voltage : 50kV,500000 Volt (V) Capacitance Tolerance : +/5% Microfarad (F) Terminal : Double Ended Famale Terminal are opposite ends Operating Temperature : 10~+40 Celsius (oC) Temperature Range : 10~+40 Celsius (oC)

Send Inquiry

High Voltage Pulse Discharge and DC Capacitor 45kV 0.01uF(10nF) Price : 1-1.2 USD ($)/Piece Minimum Order Quantity : 10 Application : High Voltage, Power, General Purpose Capacitance : 0.01uF,0.01MFD,10nF Product Type : Polypropylene Film Capacitor Current : DC Rated Voltage : 40kV,400000 Volt (V) Capacitance Tolerance : +/5% Microfarad (F) Terminal : Double Ended Famale Terminal are opposite ends Operating Temperature : 10~+40 Celsius (oC) Temperature Range : 10~+40 Celsius (oC)

Send Inquiry

25kV 0.05uF High Voltage Capacitor Price Range : 1.00 - 5.00 USD ($)/Piece Minimum Order Quantity : 20 Application : General Purpose, High Voltage, Power Capacitance : 0.05uF,0.05MFD,50nF Product Type : Polypropylene Film Capacitor Current : DC Rated Voltage : 25000 Volt (V) Capacitance Tolerance : +/10% Microfarad (F) Terminal : DoubleEnded Operating Temperature : 10~+40 Celsius (oC) Material : Film

Send Inquiry

45kV 0.015uF High Voltage Capacitor Pulse Discharge and DC Capacitor Minimum Order Quantity : 20 Application : General Purpose, High Voltage, Power Capacitance : 0.015uF,0.015MFD,15nF Product Type : Polypropylene Film Capacitor Current : DC Rated Voltage : 45000 Volt (V) Capacitance Tolerance : +/10% Microfarad (F) Terminal : DoubleEnded Operating Temperature : 10~40 Celsius (oC) Material : Film
