60nF 100kV High Voltage Pulse Capacitor

Get a Price/Quote

Product Details:

Frequency 1 Hertz (HZ)
Product Type Polypropylene Film Capacitor
Material Film
Capacitance 60nF,0.06MFD,0.06uF
Shell Plastic case
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

60nF 100kV High Voltage Pulse Capacitor Price And Quantity

60nF 100kV High Voltage Pulse Capacitor Product Specifications

Capacitance 60nF,0.06MFD,0.06uF
Shell Plastic case
Frequency 1 Hertz (HZ)
Material Film
Product Type Polypropylene Film Capacitor

60nF 100kV High Voltage Pulse Capacitor Trade Information

FOB Port Shanghai,China
Payment Terms Western Union, Paypal, Telegraphic Transfer (T/T)
Supply Ability 5000000 Per Year
Delivery Time 8 Week
Sample Available Yes
Sample Policy Sample costs shipping and taxes has to be paid by the buyer
Packaging Details 10Pcs/CTN
Certifications MSDS,RoHS,ISO9001:2015

Product Description

Specification:

Family	High Voltage capacitor ,HV pulse capacitor
Capacitance-in MFD	0.06uF
-mircofarad	0.06MFD
-in nF	60nF
Rated Voltage (DC)	100.0kV_DC
	100000V
Capacitance Tolerance	5%,10%
Max Rep -rate	1Hz
P/N.:	HV Capacitor PSE11074
Case size mm	Dimensions	Wideth	length	Height
		58	150	310
Rated voltage Reversal	20%
Max.voltage reversal	80%
Max.Peak Current	25kA
Max .RMS current	25A
Brand	Pluspark
Terminal	Single-ended
Case	Plastic case
Features	Low inductance
Application	High Voltage Pulse power supply,
Manufacturer/Supplier	Shanghai Pluspark Electronics Co.,Ltd

Rating of 100kVcapacitor

Product category	High Voltage Capacitor 100000V.DC
Item	Voltage (DC)	Capacitance-uF	Capacitance -nF
High Voltage Pulse Capacitor 1PPS	100kV	0.01uF	10nF
	100kV	0.04uF	40nF
	100kV	0.05uF	50nF
	100kV	0.06uF	60nF
	100kV	0.08uF	80nF
	100kV	0.1uF	100nF
	100kV	0.12uF	120nF
	100kV	0.2uF	200nF
	100kV	0.4uF	400nF
	100kV	0.6uF	600nF
