High Voltage Pulse Discharge and DC Capacitor 10kV 0.5uF(500nF)

1.00 - 1.20 USD ($)/Piece

Get a Price/Quote

Product Details:

Product Type Polypropylene Film Capacitor
Capacitance 0.5uF,0.5MFD,500nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 10kV,100000 Volt (V)
Capacitance Tolerance +/-5% Microfarad (F)
Temperature Range -10~+40 Celsius (oC)
Terminal Double Ended Famale Terminal are opposite ends
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

High Voltage Pulse Discharge and DC Capacitor 10kV 0.5uF(500nF) Price And Quantity

Minimum Order Quantity 10 Piece
Price Range 1.00 - 1.20 USD ($)/Piece

High Voltage Pulse Discharge and DC Capacitor 10kV 0.5uF(500nF) Product Specifications

Product Type Polypropylene Film Capacitor
Operating Temperature -10~+40 Celsius (oC)
Temperature Range -10~+40 Celsius (oC)
Capacitance Tolerance +/-5% Microfarad (F)
Capacitance 0.5uF,0.5MFD,500nF
Terminal Double Ended Famale Terminal are opposite ends
Application General Purpose High Voltage
Rated Voltage 10kV,100000 Volt (V)

High Voltage Pulse Discharge and DC Capacitor 10kV 0.5uF(500nF) Trade Information

FOB Port Shanghai
Payment Terms Western Union Paypal Telegraphic Transfer (T/T)
Supply Ability 200 Piece Per Week
Delivery Time 4-6 Week
Sample Policy Contact us for information regarding our sample policy
Packaging Details 5PCS/CTN
Main Export Market(s) South America Eastern Europe Western Europe Middle East Africa Central America Asia North America
Main Domestic Market All India
Certifications ISO9001:2015

Product Description

HIGH VOLTAGE PULSE DISCHARGE AND DC CAPACITOR 10KV 0.5uF(500nF)
Specifications
Capacitance	0.5uF/0.5MFD/500nF
Rated Voltage	10kV/10000V.DC
Capacitance Tolerance	5%
Minimum Operating Temperature	-10C
Maximum Operating Temperature	+40C
Rated Voltage Reversal	20%
MAX Peak Current	25KA
MAX RMS Current	25A
Product Category	Pulse Capacitor
Part Number	DEF11004
Case Style	Double-Ended,Plastic Case
Dimensions	L:102mm W:152mm H:58mm
Manufacturer	Shanghai Pluspark Electronics Co.,Ltd
