HV Capacitor 100kV 0.2uF 1PPS Pulse Capacitor 200nF 100000V.dc

1.00 - 1.20 USD ($)/Piece

Get a Price/Quote

Product Details:

Current DC
Frequency 1 Hertz (HZ)
Product Type Polypropylene Film Capacitor
Capacitance 0.2uF,0.2MFD,200nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 100kV,1000000 Volt (V)
Capacitance Tolerance +/-10% Microfarad (F)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

HV Capacitor 100kV 0.2uF 1PPS Pulse Capacitor 200nF 100000V.dc Price And Quantity

Price Range 1.00 - 1.20 USD ($)/Piece
Minimum Order Quantity 10 Piece

HV Capacitor 100kV 0.2uF 1PPS Pulse Capacitor 200nF 100000V.dc Product Specifications

Product Type Polypropylene Film Capacitor
Current DC
Rated Voltage 100kV,1000000 Volt (V)
Capacitance Tolerance +/-10% Microfarad (F)
Terminal Single-Ended
Operating Temperature -10~+40 Celsius (oC)
Temperature Range -10~+40 Celsius (oC)
Frequency 1 Hertz (HZ)
Application Power, High Voltage, General Purpose
Capacitance 0.2uF,0.2MFD,200nF

HV Capacitor 100kV 0.2uF 1PPS Pulse Capacitor 200nF 100000V.dc Trade Information

FOB Port Shanghai
Payment Terms Paypal, Western Union, Telegraphic Transfer (T/T)
Supply Ability 200 Piece Per Week
Delivery Time 4-6 Week
Sample Policy Contact us for information regarding our sample policy
Packaging Details 5PCS/CTN
Main Export Market(s) Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Central America, Asia, Africa
Main Domestic Market All India
Certifications ISO9001:2015

Product Description

HIGH VOLTAGE PULSE CAPACITOR 100KV 0.2uF(200nF)
Specifications
Capacitance	0.1uF/0.1MFD/100nF
Rated Voltage	100kV/100000V.DC
Capacitance Tolerance	10%
Minimum Operating Temperature	-10C
Maximum Operating Temperature	+40C
Max. Continuous Rep Rate	1pps
MAX Peak Current	25KA
MAX RMS Current	25A
Product Category	Pulse Capacitor
Part Number	PSE11078
Case Style	Single-Ended Plastic Case
Dimensions	L:216mm W:72mm H:403mm
Manufacturer	Shanghai Pluspark Electronics Co.,Ltd
