HV Discharge Pulse and DC Capacitor 2uF 5KV

1.00 - 1.20 USD ($)/Piece

Get a Price/Quote

Product Details:

Current DC
Product Type Polypropylene Film Capacitor
Capacitance 2uF,2MFD,2000nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 5kV,50000 Volt (V)
Capacitance Tolerance +/-10% Microfarad (F)
Temperature Range -10~+40 Celsius (oC)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

HV Discharge Pulse and DC Capacitor 2uF 5KV Price And Quantity

Price Range 1.00 - 1.20 USD ($)/Piece
Minimum Order Quantity 10 Piece

HV Discharge Pulse and DC Capacitor 2uF 5KV Product Specifications

Product Type Polypropylene Film Capacitor
Rated Voltage 5kV,50000 Volt (V)
Temperature Range -10~+40 Celsius (oC)
Current DC
Application General Purpose, High Voltage, Power
Capacitance Tolerance +/-10% Microfarad (F)
Capacitance 2uF,2MFD,2000nF
Operating Temperature -10~+40 Celsius (oC)
Terminal Double Ended Famale Terminal are opposite ends

HV Discharge Pulse and DC Capacitor 2uF 5KV Trade Information

FOB Port Shanghai
Payment Terms Western Union, Paypal, Telegraphic Transfer (T/T)
Supply Ability 200 Piece Per Week
Delivery Time 4-6 Week
Sample Policy Contact us for information regarding our sample policy
Packaging Details 5pcs/ctn
Main Export Market(s) Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Central America, Asia, Africa
Main Domestic Market All India
Certifications ISO9001:2015

Product Description

HIGH VOLTAGE PULSE DISCHARGE AND DC CAPACITOR 5KV 2uF(2000nF)
Specifications
Capacitance	2uF/2MFD/2000nF
Rated Voltage	5kV/5000V.DC
Capacitance Tolerance	5%
Minimum Operating Temperature	-10C
Maximum Operating Temperature	+40C
Rated Voltage Reversal	20%
MAX Peak Current	25KA
MAX RMS Current	25A
Product Category	Pulse Capacitor
Part Number	DEF11001
Case Style	Double-Ended,Plastic Case
Dimensions	L:80mm W:152mm H:58mm
Manufacturer	Shanghai Pluspark Electronics Co.,Ltd
Contact US
Phone/Whatsapp	+86 137 6117 4539
Skype	Phyllis.Hou

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Pulse Discharge And DC Capacitor' category

25kV 0.05uF High Voltage Capacitor Price Range : 1.00 - 5.00 USD ($)/Piece Minimum Order Quantity : 20 Current : DC Rated Voltage : 25000 Volt (V) Terminal : DoubleEnded Operating Temperature : 10~+40 Celsius (oC) Capacitance Tolerance : +/10% Microfarad (F) Application : General Purpose, High Voltage, Power Product Type : Polypropylene Film Capacitor Capacitance : 0.05uF,0.05MFD,50nF Material : Film

Send Inquiry

40kV 0.02uF Capacitor Price Range : 1.00 - 2.00 USD ($)/Piece Minimum Order Quantity : 20 Current : DC Rated Voltage : 40000 Volt (V) Terminal : DoubleEnded Operating Temperature : 10~+40 Celsius (oC) Capacitance Tolerance : +/10% Microfarad (F) Application : High Voltage, Power, General Purpose Product Type : Polypropylene Film Capacitor Capacitance : 0.02uF,0.02MFD,20nF Material : Film

Send Inquiry

35kV 0.03uF High Voltage Capacitor HV Pulse Discharge and DC Capacitor Price Range : 1.00 - 2.00 USD ($)/Piece Minimum Order Quantity : 20 Current : DC Rated Voltage : 35000 Volt (V) Terminal : DoubleEnded Operating Temperature : 10~+40 Celsius (oC) Capacitance Tolerance : +/10% Microfarad (F) Application : General Purpose, High Voltage, Power Product Type : Polypropylene Film Capacitor Capacitance : 0.03uF,0.03MFD,30nF Material : Film
