0.5uF 30kV High Voltage Capacitor

Get a Price/Quote

Product Details:

Frequency 1 Hertz (HZ)
Insulation Resistance 1000Mohm-uF
Product Type Polypropylene Film Capacitor
Capacitance 0.5uF,0.5MFD,500nF
Operating Temperature -10C to +40C Celsius (oC)
Rated Voltage 30kV,30000 Volt (V)
Capacitance Tolerance +/-10% (K),+/-5% (J) Microfarad (F)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

0.5uF 30kV High Voltage Capacitor Price And Quantity

Minimum Order Quantity 10 Piece

0.5uF 30kV High Voltage Capacitor Product Specifications

Operating Temperature -10C to +40C Celsius (oC)
Frequency 1 Hertz (HZ)
Product Type Polypropylene Film Capacitor
Capacitance Tolerance +/-10% (K),+/-5% (J) Microfarad (F)
Application Power, General Purpose, High Voltage
Rated Voltage 30kV,30000 Volt (V)
Capacitance 0.5uF,0.5MFD,500nF
Insulation Resistance 1000Mohm-uF

0.5uF 30kV High Voltage Capacitor Trade Information

FOB Port Shanghai,China
Payment Terms Western Union, Paypal, Telegraphic Transfer (T/T)
Supply Ability 300 Piece Per Month
Delivery Time 3 Days
Sample Available Yes
Sample Policy Sample costs shipping and taxes has to be paid by the buyer
Packaging Details 5Pcs/CTN, 10Pcs/CTN
Main Export Market(s) Australia, South America, Middle East, Africa, Western Europe, Asia, Central America, Eastern Europe, North America
Certifications ISO9001:2015 ,MSDS, RoHs

Product Description

Specification:

Manufacturer/Supplier	Shanghai Pluspark Electronics Co.,Ltd
Product	High voltage capacitor
Rated capacitance -in nF	500nF
-in uF	0.5uF, 0.5MFD
Capacitance tolerance	+/-10% (K),
Rated voltage V_R	30Kv, 30000V.DC
Max. Continuous Rep Rate	1pps
Test Voltage	1.2U_R (U_R>30KV_DC)
Terminals	Single-ended, plastic case
Case size	58x152x275mm, 58x152x248mm,
Operating temperature range	-10~+40degree C
Max .peak current	25kA

Features:

High Voltage capacitor , rep-rate: 1Hz.

Plastic case capacitor, Single-ended,

Pulse Application, like medical lithotripsy , PEMF, ESWL,Laser powersupply ,

Marx generator ,and so on.

Rating of 30kV Capacitor

Product category	High Voltage Capacitor
Voltage	Capacitance-uF	Capacitance-nF	Stock status
30kV	0.06uF	60nF	out of stock
30kV	0.1uF	100nF	In stock
30kV	0.16uF	160nF	In stock
30kV	0.20uF	200nF	In stock
30kV	0.30uF	300nF	In stock
30kV	0.32uF	320nF	In stock
30kV	0.40uF	400nF	In stock
30kV	0.50uF	500nF	In stock
30kV	0.60uF	600nF	In stock
30kV	1uF	1000nF	In stock

Stock and Delivery

Stock quantity	Available to ship
Stock	Can ship immediately
Lead time	In stock , 1 Business day Out of stock, 8-10 Weeks
Package quantity	5Pcs/CTN
