15kv 2000nf High Voltage Capacitor

1-1.2 USD ($)/Piece

Get a Price/Quote

Product Details:

Current DC
Frequency 1 Hertz (HZ)
Product Type Polypropylene Film Capacitor
Material Film
Capacitance 2uF,2MFD,2000nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 15000 Volt (V)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

15kv 2000nf High Voltage Capacitor Price And Quantity

Price 1-1.2 USD ($)/Piece
Minimum Order Quantity 10 Piece

15kv 2000nf High Voltage Capacitor Product Specifications

Frequency 1 Hertz (HZ)
Capacitance 2uF,2MFD,2000nF
Material Film
Product Type Polypropylene Film Capacitor
Operating Temperature -10~+40 Celsius (oC)
Terminal Single-Ended
Rated Voltage 15000 Volt (V)
Capacitance Tolerance +/-10% Microfarad (F)
Application General Purpose, Power, High Voltage
Current DC

15kv 2000nf High Voltage Capacitor Trade Information

FOB Port Shanghai
Payment Terms Western Union, Paypal, Telegraphic Transfer (T/T)
Supply Ability 200000 Piece Per Month
Delivery Time 4-6 Week
Sample Available Yes
Sample Policy Sample costs shipping and taxes has to be paid by the buyer
Packaging Details 4Pcs/CTN,5Pcs/CTN, 10Pcs/CTN
Main Export Market(s) Australia, South America, Western Europe, Middle East, Central America, Asia, Eastern Europe, North America, Africa
Main Domestic Market All India
Certifications ISO9001:2015 ,RoHS

Product Description

Manufacturer/Supplier	Shanghai Pluspark Electronics Co.,Ltd
Product	High voltage capacitor
Rated capacitance -in uF	2uF,2MFD
-in nF	2000nF
Capacitance tolerance	+/-10% (K),
Rated voltage V_R	15Kv, 15000V.DC
Max. Continuous Rep Rate	1pps
Terminals	Single-ended, plastic case
Case size	62x155x405mm
Operating temperature range	-10degree C~+40 degree C
Max .peak current	25kA
Max RMS current	25A
Design life	100,000 charge/discharge cycles

Rating of 15kV Capacitor

Product category	High Voltage Capacitor
Item	Voltage	Capacitance-uF	Capacitance -nF
High Voltage Pulse Capacitor	15kV	0.47uF	470nF
High Voltage Pulse Capacitor	15kV	0.6uF	600nF
High Voltage Pulse Capacitor	15kV	2uF	2000nF
