HV Pulse Capacitor 0.4uF 100kV 400nF,Dounle Ended,Plastic Case Capacitor

1.00 - 1.20 USD ($)/Piece

Get a Price/Quote

Product Details:

Current DC
Product Type Polypropylene Film Capacitor
Capacitance 0.6uF,0.6MFD,600nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 100kV,1000000 Volt (V)
Capacitance Tolerance +/-10% Microfarad (F)
Temperature Range -10~+40 Celsius (oC)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

HV Pulse Capacitor 0.4uF 100kV 400nF,Dounle Ended,Plastic Case Capacitor Price And Quantity

Price Range 1.00 - 1.20 USD ($)/Piece
Minimum Order Quantity 10 Piece

HV Pulse Capacitor 0.4uF 100kV 400nF,Dounle Ended,Plastic Case Capacitor Product Specifications

Capacitance 0.6uF,0.6MFD,600nF
Capacitance Tolerance +/-10% Microfarad (F)
Rated Voltage 100kV,1000000 Volt (V)
Terminal Doouble-Ended with Electrode
Operating Temperature -10~+40 Celsius (oC)
Application Power, High Voltage
Temperature Range -10~+40 Celsius (oC)
Current DC
Product Type Polypropylene Film Capacitor

HV Pulse Capacitor 0.4uF 100kV 400nF,Dounle Ended,Plastic Case Capacitor Trade Information

Payment Terms Western Union, Paypal, Telegraphic Transfer (T/T)
Supply Ability 200 Piece Per Week
Delivery Time 4-6 Week
Sample Policy Contact us for information regarding our sample policy
Main Export Market(s) Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Central America, Asia, Africa
Main Domestic Market All India
Certifications ISO9001:2015

Product Description

HIGH VOLTAGE PULSE CAPACITOR 100KV 0.4uF(400nF)
Specifications
Capacitance	0.4uF/0.4MFD/400nF
Rated Voltage	100kV/100000V.DC
Capacitance Tolerance	10%
Minimum Operating Temperature	-10C
Maximum Operating Temperature	+40C
MAX Peak Current	25KA
MAX RMS Current	25A
Product Category	Pulse Capacitor
Part Number	PDE11009
Dimensions	L:340mm W:400mm H115mm
Case Style	Double-Ended with Electrode,Plastic Case
Manufacturer	Shanghai Pluspark Electronics Co.,Ltd
