1pps Pulse 20kv 0.1uf High Voltage Capacitor

Get a Price/Quote

Product Details:

Current DC
Frequency 1 Hertz (HZ)
Product Type Polypropylene Film Capacitor
Material Film
Capacitance 0.1uF,0.1MFD,100nF
Operating Temperature -10~+40 Celsius (oC)
Rated Voltage 20000 Volt (V)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

1pps Pulse 20kv 0.1uf High Voltage Capacitor Price And Quantity

Price Or Price Range INR

1pps Pulse 20kv 0.1uf High Voltage Capacitor Product Specifications

Terminal Single-Ended
Product Type Polypropylene Film Capacitor
Capacitance Tolerance +/-10% Microfarad (F)
Material Film
Capacitance 0.1uF,0.1MFD,100nF
Rated Voltage 20000 Volt (V)
Current DC
Frequency 1 Hertz (HZ)
Application General Purpose, High Voltage, Power
Operating Temperature -10~+40 Celsius (oC)

1pps Pulse 20kv 0.1uf High Voltage Capacitor Trade Information

FOB Port Shanghai
Payment Terms Letter of Credit at Sight (Sight L/C), Western Union, Telegraphic Transfer (T/T)
Supply Ability 200 , Per Week
Delivery Time Week
Sample Policy Contact us for information regarding our sample policy
Packaging Details 5PCS/CTN
Main Export Market(s) North America, South America, Eastern Europe, Western Europe, Middle East, Central America, Asia, Australia, Africa
Main Domestic Market Madhya Pradesh
Certifications ISO9001

Product Description

Manufacturer/Supplier	Shanghai Pluspark Electronics Co.,Ltd
Product	High voltage capacitor
Rated capacitance -in uF	0.1uF,0.1MFD
-in nF	100nF
Capacitance tolerance	+/-10% (K),
Rated voltage V_R	20Kv, 20000V.DC
Max. Continuous Rep Rate	1pps
Terminals	Single-ended, plastic case
Case size	58x152x235mm
Operating temperature range	-10degree C~+40 degree C
Max .peak current	25kA
Max RMS current	25A
Design life	100,000 charge/discharge cycles

Rating of 20kV Capacitor

Product category	High Voltage Capacitor
Item	Voltage	Capacitance-uF	Capacitance -nF
High Voltage Capacitor	20kV	0.1uF	100nF
	20kV	0.13uF	130nF
	20kV	0.2uF	200nF
	20kV	0.4uF	400nF
	20kV	0.6uF	600nF
